Operation Description:
The function of refrigerating machine is using low pressure water vapor compressed into higher pressure vapor, so that the volume of vapor decreases, but the pressure goes up. Compressor absorbs the lower pressure of the water vapor from the evaporator, then the pressure will increase and pass into the condenser. In the condenser the vapor become high pressure liquid, through the flow valve and become low pressure liquid, after going into the evaporator, it will be evaporated and become low pressure vapor, and then go into the compressor to finish the cool circulation.
Feature:
High heat exchanging efficiency and compact structure.
The inlet and outlet are sealed well to avoid water leakage.
With insulation material to reduce heat loss.
Corrosion-resistant, long life, not easy to block.
Separate connector, more durable.
Can be use in special water quality.
Technical Parameters:
| Model | Rated Hot Water Production (L/h) | Maxium Operating Current (A) | Water Flow Rate (m³/h) | Power Supply (V/PH/Hz) | Rated Heatin Capacity (kw) | Rated Input Power (kw) | Rated Input Current (A) | Noise dB (A) |
| L-050 | 375 | 10.3 | 3.01 | 380/3/50 | 17.5 | 3.80 | 7.0 | 54 |
| L-070 | 525 | 15.5 | 4.214 | 380/3/50 | 24.5 | 5.30 | 10.0 | 54 |
| L-100 | 750 | 20.5 | 6.02 | 380/3/50 | 35.0 | 7.59 | 14.10 | 57 |
| L-120 | 900 | 24.4 | 7.22 | 380/3/50 | 42.0 | 9.11 | 16.9 | 58 |
| L-150 | 1125 | 30.7 | 9.03 | 380/3/50 | 52.5 | 11.29 | 20.9 | 58 |
| L-200 | 1500 | 43.9 | 12.90 | 380/3/50 | 75.0 | 16.13 | 29.9 | 59 |
| L-250 | 1875 | 51.1 | 15.05 | 380/3/50 | 87.5 | 19.02 | 35.2 | 61 |
| L-300 | 2250 | 55.0 | 18.06 | 380/3/50 | 105.0 | 22.83 | 42.3 | 61 |
| L-400 | 2850 | 83.37 | 24.12 | 380/3/50 | 146 | 31.70 | 56.73 | 65 |
| L-500 | 3750 | 102.3 | 30.10 | 380/3/50 | 175.0 | 38.04 | 70.5 | 65 |
| L-600 | 4000
| 119.69 | 30.10 | 380/3/50 | 211 | 45.90 | 81.99 | ≤75 |
